Its History-
Headphones originated from the earpiece, and were the only way to listen to electrical audio signals before amplifiers were developed. The first truly successful set was developed in 1910 by Nathaniel Baldwin, who made them by hand in his kitchen and sold them to the United States Navy.
Some very sensitive headphones such as those manufactured by Brandes around 1919 were commonly used for early radio work. These early headphones used moving iron drivers, either single ended or balanced armature. The requirement for high sensitivity meant no damping was used, thus the sound quality was crude. They also had very poor comfort compared to modern types, usually having no padding and too often having excessive clamping force to the head. Their impedance varied; headphones used in telegraph and telephone work had an impedance of 75 ohms. Those used with early wireless radio had to be more sensitive and were made with more turns of finer wire; impedance of 1000 to 2000 ohms was common, which suited both crystal sets and triode receivers.
In early powered radios, the headphone was part of the vacuum tube's plate circuit and had dangerous voltages on it. It was normally connected directly to the positive high voltage battery terminal, and the other battery terminal was securely grounded. The use of bare electrical connections meant that users could be shocked if they touched the bare headphone connections while adjusting an uncomfortable headset.
In 1958, John C. Koss, an audiophile and jazz musician from Milwaukee, produced the first stereo headphones. Before that, the headphones were used only in industry by telephone operators and the like.
Applications-
Headphones may be used both with fixed equipment such as CD or DVD players, home theater, personal computers and with portable devices (e.g. digital audio player/mp3 player,mobile phone, etc.). Cordless headphones are not connected via a wire, receiving a radio or infrared signal encoded using a radio or infrared transmission link, like FM, Bluetooth or Wi-Fi. These are powered receiver systems of which the headphone is only a component. Cordless headphones are used with events such as a Silent disco or Silent Gig.
In the professional audio sector headphones are used in live situations by disc jockeys with a DJ mixer and sound engineers for monitoring signal sources. In radio studios, DJs use a pair of headphones when talking to the microphone while the speakers are turned off, to eliminate acoustic feedback and monitor their own voice. In studio recordings, musicians and singers use headphones to play along to a backing track. In the military, audio signals of many varieties are monitored using headphones.
Wired headphones are attached to an audio source. The most common connectors are 6.35 mm (¼″) and 3.5 mm phone connectors. The larger 6.35 mm connector tending to be found on fixed location home or professional equipment. Sony introduced the smaller, and now widely used, 3.5 mm "minijack" stereo connector in 1979, adapting the older monophonic 3.5 mm connector for use with its Walkman portable stereo tape player. The 3.5 mm connector remains the common connector for portable application today. Adapters are available for converting between 6.35 mm and 3.5 mm devices.
Impedance-
Headphones are available with low or high impedance (typically measured at 1 kHz). Low-impedance headphones are in the range 16 to 32 ohms and high-impedance headphones are about 100-600 ohms. As the impedance of a pair of headphones increases, more voltage but less current is required to drive it, and the loudness of the headphones for a given voltage decreases. In recent years, impedance of newer headphones has generally decreased to accommodate lower voltages available on battery powered CMOS-based portable electronics. This results in headphones that can be more efficiently driven by battery powered electronics. Consequently, newer amplifiers are based on designs with relatively low output impedance.
The impedance of headphones is of concern because of the output limitations of amplifiers. A modern pair of headphones is driven by an amplifier, with lower impedance headphones presenting a larger load. Amplifiers are not ideal; they also have some output impedance that limits the amount of power they can provide. In order to ensure an even frequency response, adequate damping factor, and undistorted sound, an amplifier should have an output impedance less than 1/8 that of the headphones it is driving (and ideally as low as possible). If output impedance is large compared to the impedance of the headphones, significantly higher distortion will be present. Therefore, lower impedance headphones will tend to be louder and more efficient, but will also demand a more capable amplifier. Higher impedance headphones will be more tolerant of amplifier limitations, but will produce less volume for a given output level.
Historically, many headphones had relatively high impedance, often over 500 ohms in order to operate well with high impedance tube amplifiers. In contrast, modern transistor amplifiers can have very low output impedance, enabling lower impedance headphones. Unfortunately, this means that older audio amplifiers or stereos often produce poor quality output on some modern, low impedance headphones. In this case, an external headphone amplifier may be beneficial.
Sensitivity-
Sensitivity is a measure of how effectively an earpiece converts an incoming electrical signal into an audible sound. It thus indicates how loud the headphones will be for a given electrical drive level. It can be measured in decibels of sound pressure level per milli watt, or dB SPL/mW, which may be abbreviated to dB/mW. The sensitivity of headphones is usually between about 80 and 125 dB/mW.
Headphone sensitivity may be measured in dB/mW or dB/V. These are dB SPL (sound pressure level) measured in a standard earfor a 1 kHz sinusoidal headphone input of either one milli watt or one volt. One can convert between these two units if the impedance of the earpiece is known.
Headset-
A headset is a headphone combined with a microphone. Headsets provide the equivalent functionality of a telephone handset with hands-free operation. Among applications for headsets, besides telephone use, are aviation, theatre or television studio intercom systems, and console or PC gaming. Headsets are made with either a single-earpiece (mono) or a double-earpiece (mono to both ears or stereo). The microphone arm of headsets is either an external microphone type where the microphone is held in front of the user's mouth, or a voicetube type where the microphone is housed in the earpiece and speech reaches it by means of a hollow tube. Some headsets come in a choice of either behind-the-neck or no-headband design instead of the traditional over-the-head band.
Telephone headsets-
Telephone headsets connect to a fixed-line telephone system. A telephone headset functions by replacing the handset of a telephone. Headsets for standard corded telephones are fitted with a standard 4P4C commonly called an RJ-9 connector. Headsets are also available with 2.5 mm jack sockets for many DECT phones and other applications. Cordless Bluetooth headsets are available, and often used with mobile telephones. Headsets are widely used for telephone-intensive jobs, in particular by call centre workers. They are also used by anyone wishing to hold telephone conversations with both hands free.
For older models of telephones, the headset microphone impedance is different from that of the original handset, requiring a telephone amplifier for the telephone headset. A telephone amplifier provides basic pin-alignment similar to a telephone headset adaptor, but it also offers sound amplification for the microphone as well as the loudspeakers. Most models of telephone amplifiers offer volume control for loudspeaker as well as microphone, mute function and switching between headset and handset. Telephone amplifiers are powered by batteries or AC adaptors.
Ambient noise reduction-
Unwanted sound from the environment can be reduced by excluding sound from the ear by passive noise isolation, or, often in conjunction with isolation, by active noise cancellation.
Passive noise isolation is essentially using the body of the earphone, either over or in the ear, as a passive earplug that simply blocks out sound. The headphone types that provide most attenuation are in-ear canal headphones and closed-back headphones, both circumaural and supra aural. Open-back and earbud headphones provide some passive noise isolation, but much less than the others. Typical closed-back headphones block 8 to 12 dB, and in-ears anywhere from 10 to 15 dB.
Active noise-cancelling headphones use a microphone, amplifier, and speaker to pick up, amplify, and play ambient noise in phase-reversed form; this to some extent cancels out unwanted noise from the environment without affecting the desired sound source, which is not picked up and reversed by the microphone. They require a power source, usually a battery, to drive their circuitry. Active noise cancelling headphones can attenuate ambient noise by 20 dB or more, but the active circuitry is mainly effective on constant sounds and at lower frequencies, rather than sharp sounds and voices. Some noise cancelling headphones are designed mainly to reduce low-frequency engine and travel noise in aircraft, trains, and automobiles, and are less effective in environments with other types of noise.
Balanced Armature-
A balanced armature is a sound transducer design primarily intended to increase the electrical efficiency of the element by eliminating the stress on the diaphragm characteristic of many other magnetic transducer systems. As shown schematically in the first diagram, it consists of a moving magnetic armature that is pivoted so it can move in the field of the permanent magnet. When precisely centered in the magnetic field there is no net force on the armature, hence the term 'balanced.' As illustrated in the second diagram, when there is electric current through the coil, it magnetizes the armature one way or the other, causing it to rotate slightly one way or the other about the pivot thus moving the diaphragm to make sound.
The design is not mechanically stable; a slight imbalance makes the armature stick to one pole of the magnet. A fairly stiff restoring force is required to hold the armature in the 'balance' position. Although this reduces its efficiency, this design can still produce more sound from less power than any other. Popularized in the 1920s as Baldwin Mica Diaphragm radio headphones, balanced armature transducers were refined during World War II for use in military sound powered telephones. Some of these achieved astonishing electro-acoustic conversion efficiencies, in the range of 20% to 40%, for narrow bandwidth voice signals.
Today they are typically used only in canalphones and hearing aids, where their diminutive size is a major advantage. They generally are limited at the extremes of the hearing spectrum (e.g. below 20 Hz and above 16 kHz) and require a better seal than other types of drivers to deliver their full potential. Higher-end models may employ multiple armature drivers, dividing the frequency ranges between them using a passive crossover network. A few combine an armature driver with a small moving-coil driver for increased bass output.
The earliest loudspeakers for radio receivers used balanced armature drivers for their cones.
Benefits and limitations-
Headphones may be used to prevent other people from hearing the sound either for privacy or to prevent disturbance, as in listening in a public library. They can also provide a level of sound fidelity greater than loudspeakers of similar cost. Part of their ability to do so comes from the lack of any need to perform room correction treatments with headphones. High quality headphones can have an extremely flat low-frequency response down to 20 Hz within 3dB. Marketed claims such as 'frequency response 4 Hz to 20 kHz' are usually overstatements; the product's response at frequencies lower than 20 Hz is typically very small.
Headphones are also useful for video games that use 3D positional audio processing algorithms, as they allow players to better judge the position of an off-screen sound source (such as the footsteps of an opponent or their gun fire).
Although modern headphones have been particularly widely sold and used for listening to stereo recordings since the release of the Walkman, there is subjective debate regarding the nature of their reproduction of stereo sound. Stereo recordings represent the position of horizontal depth cues (stereo separation) via volume and phase differences of the sound in question between the two channels. When the sounds from two speakers mix, they create the phase difference the brain uses to locate direction. Through most headphones, because the right and left channels do not combine in this manner, the illusion of the phantom center can be perceived as lost. Hard panned sounds will also only be heard only in one ear rather than from one side.
Binaural recordings use a different microphone technique to encode direction directly as phase, with very little amplitude difference below 2 kHz, often using a dummy head, and can produce a surprisingly lifelike spatial impression through headphones. Commercial recordings almost always use stereo, rather than binaural, recording, because loudspeaker listening has been more popular than headphone listening.
It is possible to change the spatial effects of stereo sound on headphones to better approximate the presentation of speaker reproduction by using frequency-dependent cross-feed between the channels, or—better still—a Blumlein shuffler (a custom EQ employed to augment the low-frequency content of the difference information in a stereo signal).
Headsets can have ergonomic benefits over traditional telephone handsets. They allow call center agents to maintain better posture without needing to hand-hold a handset or tilt their head sideways to cradle it
Dangers and volume solutions-
Using headphones at a sufficiently high volume level may cause temporary or permanent hearing impairment or deafness. The headphone volume often has to compete with the background noise, especially in loud places such as subway stations, aircraft, and large crowds. Extended periods of exposure to high sound pressure levels created by headphones at high volume settings may be damaging; however, one hearing expert found that "fewer than 5% of users select volume levels and listen frequently enough to risk hearing loss." Some manufacturers of portable music devices have attempted to introduce safety circuitry that limited output volume or warned the user when dangerous volume was being used, but the concept has been rejected by most of the buying public, which favors the personal choice of high volume. Koss introduced the "Safelite" line of cassette players in 1983 with such a warning light. The line was discontinued two years later for lack of interest.
The government of France has imposed a limit on all music players sold in the country: they must not be capable of producing more than 100dBA (the threshold of hearing damage during extended listening is 80dB, and the threshold of pain, or theoretically of immediate hearing loss, is 130dB). Motorcycle and other power-sport riders benefit by wearing foam earplugs when legal to do so to avoid excessive road, engine, and wind noise, but their ability to hear music and intercom speech is enhanced when doing so. The ear can normally detect 1-billionth of an atmosphere of sound pressure level, hence it is incredibly sensitive. At very high sound pressure levels, muscles in the ear tighten the tympanic membrane and this leads to a small change in the geometry of the ossicles and stirrup that results in lower transfer of force to the oval window of the inner ear (the acoustic reflex).
Listening to music through headphones while exercising can be dangerous. Blood may be diverted from the ears to the limbs leaving the inner ear more vulnerable to damage from loud sound. A Finnish study recommended that exercisers should set their headphone volumes to half of their normal loudness and only use them for half an hour.
The usual way of limiting sound volume on devices driving headphones is by limiting output power. This has the additional undesirable effect of being dependent of the efficiency of the headphones; a device producing the maximum allowed power may not produce adequate volume in low-efficiency high-quality headphones, while possibly reaching dangerous levels in very efficient ones.
